BTD30-ER20-60
SKU
773002-04
Product Overview
BTD30
BT
Face Miling
Price Hidden
In stock
| Specifications | |
|---|---|
| [L] Cutting edge length | 69 |
| [ER] ER | 25 |
| [M] Metric Size | M14x1 |
| [A] A | 60 |
Collet chuck ER - BT with face contact - BTD
Detail 1 Application
For clamping tools with cylindrical shank in collets ER.
Detail 2 Technical Design
Runout of outer taper to inner taper < 0,003 mm. Due to adjusted taper tolerances of the ER-Inner taper and the collet taper max. runout of < 8 µ at 2,5 X D.
| Weight | 0.440000 |
|---|---|
| Application | Milling |
| Clamping System | Collet chuck ER - BT with face contact - BTD |
| ER (Size) | 25 |
| Shank Size | BTD 30 ISO 7388-2 JD |
| Type Accessories | BTD 30 |
| Version | Extra Short |
| Connection Code | BT |
| Type of Taper | BT Double Contact |
| Coolant supply property | No |
| Grooving | Parting off |
| Brand | Schussler |
| Attribute set | Spindle Tooling |
