ZBMT13T304R-GF-15D PR1535
SKU
TLC40143
Product Overview
ZBMT
Heat Resistant Materials
Stainless Steel
Regular Grain Carbide
PVD
Face Miling
Price Hidden
In stock
Login to see stock availability.
| Specifications | |
|---|---|
| [RE] Corner Radius | 0.40 |
| [IC] Inscribed Circle | 6.35 |
| [S] Insert Thickness | 3.97 |
| [AN] Clearance Angle Major | 5° |
| [D1] Hole Diameter | 3.70 |
Turning Insert Positive Carbide Coated
| Weight | 0.005000 |
|---|---|
| Application | ISO Turning |
| Coating | PVD |
| Chipbreaker Size | Finishing |
| Grade Manufacturers Designation | PR1535 |
| Primary Workpiece Material | Stainless Steel, Heat Resistant Materials |
| Tool Type | Indexable Inserts |
| Tool Material | Regular Grain Carbide |
| Application Category | Undercutting, Copying, Profiling, V-Shape Slotting, Tapering |
| Insert Side Count | Positive |
| Coolant supply property | No |
| Number of Cutting Edges | 2 |
| Grooving | Parting off |
| Tool Style | ZBMT |
| Insert Mounting Style Code | Screw |
| Brand | Kyocera |
| Coating / Composition | MEGACOAT NANO |
| Cutting Edge Style | Tip Angle 25° |
| Usage Classification | Continuous to Light Interruption |
| Insert Size | ZB-13T3 |
| Chip Breaker Manufacturers Designation | GF |
