ER20-25-164
SKU
119-51
Product Overview
ER20
Face Miling
Price Hidden
In stock
| Specifications | |
|---|---|
| [L] Cutting edge length | 70 |
| [D1] Diameter | 25 |
| [ER] ER | 20 |
| [A] A | 164 |
Collet chuck extension - Mini
Detail 1 Application
For the extension of tool holders. Cylindrical shank can be clamped in end mill holder or Collet Chuck.
Detail 2 Technical Design
Runout of the inner tape to the shank D <0.005mm
| Weight | 0.520000 |
|---|---|
| Application | Milling |
| Clamping System | Collet chuck extension - Mini |
| D | 7472 |
| Diameter | 25 |
| ER (Size) | 20 |
| Type Accessories | Collet Chuck Extention |
| d | 21521,9566 |
| Coolant supply property | No |
| Grooving | Parting off |
| Brand | Schussler |
| Attribute set | Spindle Tooling |
Currently Holders Selection Are Not Available Please Visit Back Later.
