EZBR035035HP-005F PR1225
SKU
TKB03025
Heat Resistant Materials
Steel
Micro Grain Carbide
PVD
Face Miling
Price Hidden
In stock
Login to see stock availability.
| Specifications | |
|---|---|
| [RE] Corner Radius | 0.05 |
| [DCON] Connection Diameter | 3.50 |
| [WF] Cutting Edge Distance | 1.60 |
| [DMIN] Minimum Bore Diameter | 3.5 |
| [WF2] Cutting Edge Distance Secondary | 0.50 |
| [GAN] Insert Rake Angle | 18 |
| [LF] Functional Length | 41.90 |
| [LU] Usable Length | 15.00 |
| [H] Shank Height | 3.20 |
Micro Turning Bar Carbide
| Weight | 0.005000 |
|---|---|
| Application | Swiss Turning |
| Coating | PVD |
| Grade Manufacturers Designation | PR1225 |
| Primary Workpiece Material | Steel, Heat Resistant Materials |
| Tool Type | Indexable Inserts |
| Application Category | Micro Boring |
| Coolant supply property | No |
| Rake Angle Axial (Degree) | 0 |
| Tool Material | Micro Grain Carbide |
| Grooving | Parting off |
| Number of Cutting Edges | 1 |
| Tool Style | EZB-HP |
| Cutting Edge Distance Secondary | 0.50 |
| Rake Angle Radial (Degree) | -12 |
| Insert Rake Angle (Degree) | 18 |
| Insert Mounting Style Code | Screw |
| Brand | Kyocera |
| Tool Entering Angle (Degree) | 95 |
| Usable Length | 15.00 |
| Coating / Composition | MEGACOAT |
| Shank Height | 3.20 |
