GFVL2525M-201A
SKU
THC04937
Product Overview
GFV
Face Miling
Price Hidden
In stock
Login to see stock availability.
| Specifications | |
|---|---|
| [CDX] Max Depth of Cut | 02.20 |
| [CW MAX] Edge Tolerance | 3.40 |
| [B] Shank Width | 25.00 |
| [HF] Cutting Edge Height | 26.00 |
| [LH] Head Length | 23.00 |
| [WF] Cutting Edge Distance | 32.00 |
| [DAXN_min] Minimum Face Groove Diameter | 20.00 |
| [DAXX_max] Maximum Face Groove Diameter | No Maximum |
| [LF] Functional Length | 150.00 |
| [H] Shank Height | 25.00 |
| [CW] Cutting Width | 2.00 - 3.40 |
Face Grooving Toolholder
| Weight | 0.711000 |
|---|---|
| Application | Grooving |
| Tool Type | Indexable Holders |
| Max Depth of Cut | 02.20 |
| Coolant supply property | No |
| Minimum Face Groove Diameter | 20.00 |
| Maximum Face Groove Diameter | No Maximum |
| Grooving | Externally Axial Grooving |
| Tool Style | GFV |
| Cutting Width Minimum | 2.00 |
| Cutting Width Maximum | 3.40 |
| Insert Mounting Style Code | Top Clamp |
| Brand | Kyocera |
| Shank Height | 25.00 |
| Cutting Width | 2.00 - 3.40 |
