LPGT010210ER-GM PR1835
SKU
TLU00095
Product Overview
LPGT
Heat Resistant Materials
Stainless Steel
Steel
PVD
Face Miling
Price Hidden
In stock
Login to see stock availability.
| Specifications | |
|---|---|
| [RE] Corner Radius | 1.00 |
| [S] Insert Thickness | 2.19 |
| [INSL] Insert length | 06.26 |
| [W1] Insert Width | 4.19 |
| [D1] Hole Diameter | 2.10 |
Milling Insert Carbide Coated
| Weight | 0.001000 |
|---|---|
| Application | Milling |
| Coating | PVD |
| Primary Workpiece Material | Steel, Stainless Steel, Heat Resistant Materials |
| Grade Manufacturers Designation | PR1835 |
| Tool Type | Indexable Inserts |
| Coolant supply property | No |
| Application Category | Facing, Helical Milling, Shouldering, Slotting, Pocketing, Plunging, Ramping, High Feed |
| Cutting Range | Roughing |
| Number of Cutting Edges | 2 |
| Insert Side Count | Positive |
| Grooving | Parting off |
| Tool Style | LPGT |
| Insert Mounting Style Code | Screw |
| Brand | Kyocera |
| Coating / Composition | MEGACOAT NANO EX |
| Cutting Edge Style | Honed Edge / General Purpose |
| Insert length | 06.26 |
| Insert Size | LP-0102 |
| Insert Width | 4.19 |
| Chip Breaker Manufacturers Designation | ER-GM |
