LOMU150508ER-GH CA6535
SKU
TMA04358
Product Overview
LOMU
Heat Resistant Materials
Stainless Steel
CVD
Face Miling
Price Hidden
In stock
Login to see stock availability.
| Specifications | |
|---|---|
| [RE] Corner Radius | 0.80 |
| [S] Insert Thickness | 5.60 |
| [L] Cutting edge length | 15.70 |
| [BS] Wiper Edge | 1.80 |
| [W1] Insert Width | 9.20 |
| [D1] Hole Diameter | 4.80 |
Milling Insert Carbide Coated
| Weight | 0.003000 |
|---|---|
| Application | Milling |
| Coating | CVD |
| Primary Workpiece Material | Stainless Steel, Heat Resistant Materials |
| Grade Manufacturers Designation | CA6535 |
| Tool Type | Indexable Inserts |
| Wiper Edge | 1.80 |
| Coolant supply property | No |
| Application Category | Facing, Helical Milling, Shouldering, Slotting |
| Cutting Range | Roughing |
| Number of Cutting Edges | 4 |
| Insert Side Count | Positive |
| Grooving | Parting off |
| Tool Style | LOMU |
| Insert Mounting Style Code | Screw |
| Brand | Kyocera |
| Coating / Composition | TiCN/Al2O3/TiN |
| Cutting Edge Style | Honed Edge / Tough Edge |
| Insert Size | LO-1505 |
| Insert Width | 9.20 |
| Chip Breaker Manufacturers Designation | ER-GH |
