SOMT100420ER-LD CA6535
SKU
TMA05608
Product Overview
SOMT
Heat Resistant Materials
Stainless Steel
CVD
Face Miling
Price Hidden
In stock
Login to see stock availability.
| Specifications | |
|---|---|
| [RE] Corner Radius | 2.00 |
| [IC] Inscribed Circle | 10.45 |
| [S] Insert Thickness | 4.58 |
| [BS] Wiper Edge | 0.90 |
| [AN] Clearance Angle Major | 16° |
| [D1] Hole Diameter | 4.60 |
Milling Insert Carbide Coated
| Weight | 0.003000 |
|---|---|
| Application | Milling |
| Coating | CVD |
| Primary Workpiece Material | Stainless Steel, Heat Resistant Materials |
| Grade Manufacturers Designation | CA6535 |
| Tool Type | Indexable Inserts |
| Wiper Edge | 0.90 |
| Coolant supply property | No |
| Application Category | Facing, Helical Milling, Shouldering, Slotting, Pocketing, Plunging, Ramping, High Feed |
| Cutting Range | Roughing |
| Number of Cutting Edges | 4 |
| Insert Side Count | Negative |
| Grooving | Parting off |
| Tool Style | SOMT |
| Insert Mounting Style Code | Screw |
| Brand | Kyocera |
| Coating / Composition | TiCN/Al2O3/TiN |
| Cutting Edge Style | Honed Edge |
| Insert Size | SO-1004 |
| Chip Breaker Manufacturers Designation | ER-LD |
